{0x38, 0x44, 0x44, 0x44, 0x44, 0x44, 0x38, 0x00}, //0
{0x10, 0x30, 0x50, 0x10, 0x10, 0x10, 0x7C, 0x00}, //1

{0x38, 0x44, 0x44, 0x08, 0x10, 0x20, 0x7E, 0x00}, //2
{0x38, 0x44, 0x44, 0x18, 0x44, 0x44, 0x38, 0x00}, //3
{0x48, 0x48, 0x48, 0x7E, 0x08, 0x08, 0x08, 0x00}, //4
{0x7C, 0x40, 0x40, 0x38, 0x04, 0x44, 0x38, 0x00}, //5
{0x38, 0x40, 0x40, 0x38, 0x44, 0x44, 0x38, 0x00}, //6

{0x7C, 0x44, 0x08, 0x08, 0x10, 0x10, 0x10, 0x00}, //7
{0x38, 0x44, 0x44, 0x38, 0x44, 0x44, 0x38, 0x00}, //8
{0x3C, 0x44, 0x44, 0x3C, 0x04, 0x04, 0x04, 0x00}, //9
{0x10, 0x10, 0x10, 0x10, 0x10, 0x00, 0x10, 0x00} //!
};

/* 표시내용 */
char *Str_Top = "INMA LAND";

char *Str_Bot = "WELCOME";

int Top_Count=0, Bot_Count=0; //글자 개수
int T_Count=0, B_Count=0; //쉬프트 횟수
int Light_t_Delay=0, Light_b_Delay=0; //이동속도 제어용
int Check_Top1=0, Check_Top2=0, Check_Top3=0; //Top 모듈 데이터
int Check_Bot1=0, Check_Bot2=0, Check_Bot3=0; //Bot 모듈 데이터
int Top_Red = 1, Top_Green = 1; //Top RED, GREEN 제어용
int Bot_Red = 1, Bot_Green = 1; //Bot RED, GREEN 제어용
int inter = 0;

void GPIO_Configuration(void)
{
GPIO_InitTypeDef GPIO_InitStructure;

/* Configure IO connected to RED GREEN ENABLE LATCH CLOCK*/
GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0 | GPIO_Pin_1 | GPIO_Pin_2 | GPIO_Pin_3 |

GPIO_Pin_4;
GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Out_PP;
GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;
GPIO_Init(GPIOA, &GPIO_InitStructure);

/* Configure IO connected to A0 A1 A2 A3 */
