roFlag=True
                                # 어느 방향으로 각도를 계산할지 정하는 플래그
                                dx=plateList[0][0]-plateList[3][0]
                                #x 증가량
                                dy=abs(plateList[0][1]-plateList[3][1])
                                #y 증가량
                                if plateList[0][1]<plateList[3][1]:roFlag=False
                                #y 축을 비교하여 어느 방향으로 각도를 구할지 계산
                                inCl=dy/dx
                                # 기울기를 계산한다
                                atan=math.atan(inCl)
                                # 아크 탄젠트를 이용하여 각도를 구한다
                                atan=math.degrees(atan)
                                # 단위를 'radian' 으로 바꾼다


                                M=None
                                # 기울여야하는 각도를 저장하기위한 변수
                                if roFlag:
                                    center=(plateList[0][0],plateList[0][1])
                                    # 센터를 지정
                                    M=cv2.getRotationMatrix2D(center,atan,1)
                                    # 다음 방향으로 atan      만큼 기울인다
                                else:
                                    center=(plateList[3][0],plateList[3][0])
                                    # 센터를 지정
                                    M=cv2.getRotationMatrix2D(center,-atan,1)
                                    # 다음 방향으로 –     atan  만큼 기울인다


                                num_rows,num_cols=image.shape[:2]
                                #image 의 0 번과 1  번을 각각 저장한다
                                dst=cv2.warpAffine(ori2,M,(num_cols,num_rows))
                                # 최종적으로 각도를 조정


                                startPos=()
                                # 최종적인 번호판 부분의 왼쪽 위 좌표
                                endPos=()
                                # 최종적인 번호판 부분의 오른쪽 아래 좌표
                                #y 좌표에 따라서 변경
                                if plateList[0][1] < plateList[3][1]:
                                  startPos=(int(round(plateList[0][0]+
                                  plateList[0][2]*2.2)),int(round(plateList[0][1]-plateList[0][3]*0.5)))
                                  endPos=(int(round(-plateList[0][0]-plateList[0][2]+plateList[3][0]*1.99))
                                 ,int(round(plateList[3][1]+plateList[3][3]*1.5)))
                                else:
                                 startPos=(int(round(plateList[0][0]+plateList[0][2]*2.2)),
