for d1 in contour_list:
matched_contours_idx = []
for d2 in contour_list:
if d1['idx'] == d2['idx']:
continue
dx = abs(d1['cx'] - d2['cx'])
dy = abs(d1['cy'] - d2['cy'])
diagonal_length1 = np.sqrt(d1['w'] ** 2 + d1['h'] ** 2)
distance = np.linalg.norm(np.array([d1['cx'], d1['cy']]) - np.array([d2['cx'],
d2['cy']]))
if dx == 0:
angle_diff = 90
else:
angle_diff = np.degrees(np.arctan(dy / dx))
area_diff = abs(d1['w'] * d1['h'] - d2['w'] * d2['h']) / (d1['w'] * d1['h'])
width_diff = abs(d1['w'] - d2['w']) / d1['w']
height_diff = abs(d1['h'] - d2['h']) / d1['h']
if distance < diagonal_length1 * MAX_DIAG_MULTIPLYER \
and angle_diff < MAX_ANGLE_DIFF and area_diff < MAX_AREA_DIFF \
and width_diff < MAX_WIDTH_DIFF and height_diff < MAX_HEIGHT_DIFF:
matched_contours_idx.append(d2['idx'])
# append this contour
matched_contours_idx.append(d1['idx'])
if len(matched_contours_idx) < MIN_N_MATCHED:
continue
matched_result_idx.append(matched_contours_idx)
unmatched_contour_idx = []
for d4 in contour_list:
if d4['idx'] not in matched_contours_idx:
unmatched_contour_idx.append(d4['idx'])
unmatched_contour = np.take(possible_contours, unmatched_contour_idx)

# recursive
recursive_contour_list = find_chars(unmatched_contour)

for idx in recursive_contour_list:
matched_result_idx.append(idx)
break
return matched_result_idx

result_idx = find_chars(possible_contours)
matched_result = []
for idx_list in result_idx:
matched_result.append(np.take(possible_contours, idx_list))
# visualize possible contours
