void UART_puts_DEC(UART_HandleTypeDef uart,int num);
void UART_puts_HEX(UART_HandleTypeDef uart,int num);

15) 소프트웨어 - “GPIO.h"

#include "stm32f4xx_hal.h"
#ifndef GPIO_H
#define GPIO_H
#define ON_FAN1 GPIOB->ODR |= 0x0008

#define OFF_FAN1 GPIOB->ODR &= ~0x0008

#define ON_FAN2 GPIOB->ODR |= 0x0010
#define OFF_FAN2 GPIOB->ODR &= ~0x0010

#define ON_FAN3 GPIOB->ODR |= 0x0020

#define OFF_FAN3 GPIOB->ODR &= ~0x0020

#define ON_SSR1 GPIOB->ODR |= 0x0040
#define OFF_SSR1 GPIOB->ODR &= ~0x0040

#define ON_SSR2 GPIOB->ODR |= 0x0080
#define OFF_SSR2 GPIOB->ODR &= ~0x0080

#define ON_SSR3 GPIOB->ODR |= 0x0100
#define OFF_SSR3 GPIOB->ODR &= ~0x0100

#define SET_SPI_CS GPIOB->ODR |= 0x0200
#define RESET_SPI_CS GPIOB->ODR &= ~0x0200

#define ON_LED1 GPIOC->ODR |= 0x0100
#define OFF_LED1 GPIOC->ODR &= ~0x0100

#define ON_LED2 GPIOC->ODR |= 0x0200
#define OFF_LED2 GPIOC->ODR &= ~0x0200

#define ON_LED3 GPIOC->ODR |= 0x0400
