GsNReg = 0x27
CWGsPReg = 0x28
ModGsPReg = 0x29
TModeReg = 0x2A
TPrescalerReg = 0x2B
TReloadRegH = 0x2C
TReloadRegL = 0x2D
TCounterValueRegH = 0x2E
TCounterValueRegL = 0x2F
Reserved30 = 0x30
TestSel1Reg = 0x31
TestSel2Reg = 0x32
TestPinEnReg = 0x33
TestPinValueReg = 0x34
TestBusReg = 0x35
AutoTestReg = 0x36
VersionReg = 0x37
AnalogTestReg = 0x38
TestDAC1Reg = 0x39
TestDAC2Reg = 0x3A
TestADCReg = 0x3B
Reserved31 = 0x3C
Reserved32 = 0x3D
Reserved33 = 0x3E
Reserved34 = 0x3F
serNum = []
def __init__(self, dev='/dev/spidev0.0', spd=1000000):
spi.openSPI(device=dev,speed=spd)
GPIO.setmode(GPIO.BOARD)
GPIO.setup(22, GPIO.OUT)
GPIO.output(self.NRSTPD, 1)
self.MFRC522_Init()
def MFRC522_Reset(self):
self.Write_MFRC522(self.CommandReg, self.PCD_RESETPHASE)
def Write_MFRC522(self, addr, val):
spi.transfer(((addr<<1)&0x7E,val))
def Read_MFRC522(self, addr):
val = spi.transfer((((addr<<1)&0x7E) | 0x80,0))
return val[1]
