while(i < 4):
buff.append(serNum[i])
i = i +1
# Now we start the authentication itself
(status, backData, backLen) = self.MFRC522_ToCard(self.PCD_AUTHENT,buff)
# Check if an error occurred
if not(status == self.MI_OK):
print "AUTH ERROR!!"
if not (self.Read_MFRC522(self.Status2Reg) & 0x08) != 0:
print "AUTH ERROR(status2reg & 0x08) != 0"
# Return the status
return status

def MFRC522_StopCrypto1(self):
self.ClearBitMask(self.Status2Reg, 0x08)
def MFRC522_Read(self, blockAddr):
recvData = []
recvData.append(self.PICC_READ)
recvData.append(blockAddr)
pOut = self.CalulateCRC(recvData)
recvData.append(pOut[0])
recvData.append(pOut[1])
(status, backData, backLen) = self.MFRC522_ToCard(self.PCD_TRANSCEIVE, recvData)
if not(status == self.MI_OK):
print "Error while reading!"
i = 0
if len(backData) == 16:
print "Sector "+str(blockAddr)+" "+str(backData)

def MFRC522_Write(self, blockAddr, writeData):
buff = []
buff.append(self.PICC_WRITE)
buff.append(blockAddr)
crc = self.CalulateCRC(buff)
buff.append(crc[0])
buff.append(crc[1])
(status, backData, backLen) = self.MFRC522_ToCard(self.PCD_TRANSCEIVE, buff)
if not(status == self.MI_OK) or not(backLen == 4) or not((backData[0] & 0x0F) == 0x0A):
status = self.MI_ERR

print str(backLen)+" backdata &0x0F == 0x0A "+str(backData[0]&0x0F)
if status == self.MI_OK:
i = 0
buf = []
while i < 16:
