wr_reg(0x35, 0x0106);
wr_reg(0x36, 0x0B02);
wr_reg(0x37, 0x0302);
wr_reg(0x38, 0x0707);
wr_reg(0x39, 0x0007);
wr_reg(0x3C, 0x0600);
wr_reg(0x3D, 0x020B);

/* Set GRAM area --------------------------------------------------*/
wr_reg(0x50, 0x0000); /* Horizontal GRAM Start Address */
wr_reg(0x51, (HEIGHT-1)); /* Horizontal GRAM End Address */
wr_reg(0x52, 0x0000); /* Vertical GRAM Start Address */
wr_reg(0x53, (WIDTH-1)); /* Vertical GRAM End Address */
wr_reg(0x60, 0x2700); /* Gate Scan Line */
wr_reg(0x61, 0x0001); /* NDL,VLE, REV */
wr_reg(0x6A, 0x0000); /* Set scrolling line */

/* Partial Display Control -------------------------------------------------*/
wr_reg(0x80, 0x0000);
wr_reg(0x81, 0x0000);
wr_reg(0x82, 0x0000);
wr_reg(0x83, 0x0000);
wr_reg(0x84, 0x0000);
wr_reg(0x85, 0x0000);

/* Panel Control ----------------------------------------------------*/
wr_reg(0x90, 0x0010);
wr_reg(0x92, 0x0000);
wr_reg(0x93, 0x0003);
wr_reg(0x95, 0x0110);
wr_reg(0x97, 0x0000);
wr_reg(0x98, 0x0000);

/* Set GRAM write direction and BGR = 1
I/D=10 (Horizontal : increment, Vertical : increment)
AM=1 (address is updated in vertical writing direction) */
wr_reg(0x03, 0x1038);
// wr_reg(0x03, 0x1018);

wr_reg(0x07, 0x0173); /* 262K color and display ON */
}
