else if(DeviceCode==0x9325||DeviceCode==0x9328)
{
wr_reg(0x00e7,0x0010);
wr_reg(0x0000,0x0001); //start internal osc
wr_reg(0x0001,0x0100);
wr_reg(0x0002,0x0700); //power on sequence
wr_reg(0x0003,(1<<12)|(1<<5)|(1<<4)|(1<<3) ); //65K
wr_reg(0x0004,0x0000);
wr_reg(0x0008,0x0207);
wr_reg(0x0009,0x0000);
wr_reg(0x000a,0x0000); //display setting
wr_reg(0x000c,0x0001); //display setting
wr_reg(0x000d,0x0000); //0f3c
wr_reg(0x000f,0x0000);
//Power On sequence //
wr_reg(0x0010,0x0000);
wr_reg(0x0011,0x0007);
wr_reg(0x0012,0x0000);
wr_reg(0x0013,0x0000);
delay(2);
wr_reg(0x0010,0x1590);
wr_reg(0x0011,0x0227);
delay(2);
wr_reg(0x0012,0x009c);
delay(2);
wr_reg(0x0013,0x1900);
wr_reg(0x0029,0x0023);
wr_reg(0x002b,0x000e);
delay(2);
wr_reg(0x0020,0x0000);
wr_reg(0x0021,0x0000);
delay(2);
wr_reg(0x0030,0x0007);
wr_reg(0x0031,0x0707);
wr_reg(0x0032,0x0006);
wr_reg(0x0035,0x0704);
wr_reg(0x0036,0x1f04);
wr_reg(0x0037,0x0004);
wr_reg(0x0038,0x0000);
wr_reg(0x0039,0x0706);
wr_reg(0x003c,0x0701);
